Specifications

Electric

Dimensions

Overall Length: 167.5 in (425.5 cm)
Overall Width: 49.5 in (123 cm)
Overall Height (No Canopy): 45.5 in (123 cm) (Top of steering wheel)
Overall Height (With Canopy): 76.0 in (193 cm)
Wheel Base:123.4 in (313.7 cm)
Front Wheel Track: 36.0 in (91.4 cm)
Rear Wheel Track 38.0 in (97 cm)
Ground Clearance @ Differential: 4.3 in (11 cm)

Vehicle Power

Power Source: 48 Volts DC
Motor Type: Shunt Wound
Continuous Horsepower (kW): 2.5 hp (1.9 kW) Continuous
Intermittent Horsepower: 18.1 hp (13.5 kW) Peak
Electrical System: 48 Volt
Batteries (Qty, Type): Eight, 6 Volt Deep Cycle
Key or Pedal Start: Pedal Start
Battery Charger: 48 VDC Delta Q, 120/230 VAC UL & CSA
Speed Controller: 400 Amp Precision Drive System (PDS)
Drivetrain: Motor Shaft Direct Drive
Transaxle: Differential with Helical Gears
Gear Selection: Dash-Mounted Forward-Neutral-Reverse
Rear Axle Ratio: 14.7:1

Performance

Seating Capacity: 8 Person
Dry Weight: 1142 lb (519 kg) (Without Batteries)
Curb Weight: 1632 lb (742 kg)
Vehicle Load Capacity: 1600 lb (727 kg)
Cargo Deck Capacity: 400 lb (181.45 kg)
Outside Clearance Circle: 33.0 ft (10.1 m)
Speed (Level Ground): 13 mph ± 0.5 mph (21 kph ± 0.8 kph)

Steering and Suspension

Steering Self-Compensating Reduction Rack and Pinion
Front Suspension Leaf Springs with Hydraulic Shock Absorbers
Rear Suspension Leaf Springs with Hydraulic Shock Absorbers
Service Brake: 4 Wheel Hydraulic Brakes, Front Disk, Rear Drum
Parking Brake: Self-Compensating Single Point Engagement
Front Tires: Kenda Load Star, 50 psi
Rear Tires: Kenda Load Star, 70 psi

Body & Chassis

Frame: Welded Steel. DuraShield Powder Coat
Front Body and Finish Injection molded TPO
Rear Body and Finish Fiberglass & Gelcoat
Standard Color: Patriot Blue
Gas

Dimensions

Overall Length: 167.5 in (425.5 cm)
Overall Width: 49.5 in (125.7 cm)
Overall Height (No Canopy): 45.5 in (115.6 cm) (Top of steering wheel)
Overall Height (With Canopy): 76.0 in (193 cm)
Wheel Base: 123.4 in (313.7 cm)
Front Wheel Track: 36.0 in (91.4 cm)
Rear Wheel Track : 38.0 in (97 cm)
Ground Clearance @ Differential: 3.0 in (7.6 cm)

Vehicle Power

Power Source: 4 Cycle 24.5 cu in (401 cc). Low Emission
Valve Train: Single Cynlinder OHV
Horsepower (kW) 13.5 hp (9.7 kW) Exceeds SAE J1940 Standard
Electrical System Starter/Generator, Solid-State Regulator
Batteries (Qty, Type): One, 12-Volt Maintenance Free
Air Cleaner: Replaceable Dry Cartridge
Lubrication: Pressurized Oil System
Oil Filter Spin-On
Cooling System: Air Cooled
Fuel Capacity: 5.8 Gallon (22.0L) tank
Drivetrain: Continuously Variable Transmission (CVT)
Transaxle: Differential with Helical Gears
Gear Selection: Forward-Reverse
Rear Axle Ratio: 11.43:1 (Forward), 13.57:1 (Reverse)

Performance

Seating Capacity 8 Person
Dry Weight: 1225 lb (557 kg)
Curb Weight: 1265 lb (575 kg)
Vehicle Load Capacity: 1600 lb (727 kg)
Cargo Deck Capacity 400 lb (181.45 kg)
Outside Clearance Circle 33.0 ft (10.1 m)
Speed (level ground) 16 mph ± 0.5 (26 kph ± 0.8 kph)
